Alarm monitoring stations - communicator modules

Communicators for monitoring stations

Alarm monitoring stations

Communicator with 8 contact inputs and WIFI + 2G (GPRS) network connection

Features

8 contact inputs with configurable event codes

2 parallel communication channels, WIFI and 2G (GPRS) mobile communication

Signalling to 2 independent remote monitoring receivers in SIA IP format

Setup via PC software, USB connection

TTL/RS-232 serial port for remote programming of alarms (Paradox and DSC)

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

Remote monitoring device, for equipment with contact outputs
(e.g. alarm panel, fire alarm system, ATM)
-
I8 W2G
Read more
Communicator with 8 contact inputs and WIFI + 4G (LTE) network connection

Features

8 contact inputs with configurable event codes

2 parallel communication channels, WIFI and 4G (LTE) mobile communication

Signalling to 2 independent remote monitoring receivers in SIA IP format

Setup via PC software, USB connection

TTL/RS-232 serial port for remote programming of alarms (Paradox and DSC)

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

Remote monitoring device, for equipment with contact outputs
(e.g. alarm panel, fire alarm system, ATM)
-
I8 W4G
Read more
Digital receiver for monitoring stations, up to 2500 endpoints

Features

Compact monitoring receiver, handling up to 2500 endpoints

Static or DHCP network configuration

USB and serial (RS-232) interface for PC connection

Receiving SIA DC-09 protocol messages

Encrypted communication option (AES-128)

Individual monitoring settings for each account

Account identification also by IP Address/MAC/IMEI

Continuous monitoring of LAN and WAN connection

Client IP address display in monitoring software

Local programming via USB, remote programming through IP network

Event list monitoring from web browser

Firmware update function

Application

Remote monitoring receiver for SIA IP protocol signalling communicators
-
IPR-2500
Read more
Digital receiver for monitoring stations, up to 5000 endpoints
Features

Monitor and receive signals from up to 5000 endpoints

Static or DHCP network configuration

Monitoring of test code, with a time individually defined for each endpoint

ONLINE i.e. active and OFFLINE i.e. disconnected devices indication

Individual disabling of endpoint devices, blocking unwanted communication

USB and serial (RS-232) interface for PC connection

Receiving SIA DC-09 protocol messages

Encrypted communication option (AES-128 or AES-256)

Individual monitoring settings for each account

Continuous monitoring of LAN and WAN connection

Client IP address display in monitoring software

Local programming via USB, remote programming through IP network

Event list monitoring from web browser

Firmware update function
Application

Remote monitoring receiver for SIA IP protocol signalling communicators
-
IPR-5000
Read more
Signaling and control over ethernet (LAN) connection
Features

Ethernet network connection (LAN)

Emulates landline (TIP/RING) for alarm system

Automatic recognition of Contact ID and SIA FSK Level 1.2 reporting formats

Converting any Contact ID report codes to „push notification text message”
and forwarding to smartphone applications

Remote monitoring connection to 2 independent SIA DC-09 IP receivers

Support of dynamic (DHCP) and static IP assignment

2 contact inputs with unique signalling

Controlling of alarm panels with 2 relay (arm/disarm, up to 2 partitions)

Remote setup of alarm panels via internet (built in TTL/RS-232 serial ports)

Setup via PC program, USB connection (no router setup required)

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

Transmission of alarm events to monitoring station and mobile App

Remote access, download and configuration of alarms systems

Monitoring of contact events, and remote control of relays
-
LANCOM module
Read more
Remotely manageable, remote monitoring communicator for alarm panels with 2G (GPRS) connection
Features

2G network connection (GPRS)

Emulates landline (TIP/RING) for alarm system

Automatic recognition of Contact ID and SIA FSK Level 1,2 report formats

Remote monitoring connection to 2 independent SIA DC-09 IP receivers

2 contact inputs with unique signalling

Setup via PC program, USB connection

TTL/RS-232 serial port for remote programming of alarm panel

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

High-tech communicator of monitoring stations

Remote programming of alarm panels
-
SC-2G
Read more
Remotely manageable, remote monitoring communicator for alarm panels with 4G (LTE) connection
Features

4G network connection (LTE)

Emulates landline (TIP/RING) for alarm system

Automatic recognition of Contact ID and SIA FSK Level 1,2 report formats

Remote monitoring connection to 2 independent SIA DC-09 IP receivers

2 contact inputs with unique signalling

Setup via PC program, USB connection

TTL/RS-232 serial port for remote programming of alarm panel

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

Cutting-edge communicator of monitoring stations

Remote programming of alarm panels
-
SC-4G
Read more
Remotely manageable, remote monitoring communicator for alarm panels with 4G (LTE) + PSTN connection

Features

Primary 4G (LTE) network connection and PSTN backup signalling

Emulates landline (TIP/RING) for alarm system

Signalling via 4G or PSTN network, selected by the alarm system

Managing the PSTN line between the alarm system and the telephone set

Automatic recognition of Contact ID and SIA FSK Level 1,2 report formats

Remote monitoring connection to 2 independent SIA DC-09 IP receivers

1 contact inputs with unique signalling

1 remotely controlled relay output

Setup via PC program, USB connection

TTL/RS-232 serial port for remote programming of alarm panel

Full remote management via WEB interface (configuration, diagnostics)

AES-128 encrypted communication option

Application

High security level communicator of monitoring stations

Remote programming of alarm panels
-
SC-4G PSTN
Read more
Cost-effective compact remote monitoring communicator for alarm panels with 2G (GPRS) connection
Features

2G network connection (GPRS)

Emulates landline (TIP/RING) for alarm system

Remote monitoring connection to 2 independent SIA DC-09 IP receivers

2 contact inputs with unique signalling

Setup via PC program, USB connection

Application

Entry-level communicator of monitoring stations
-
SC-GPRS
Read more
